Description
【Features】
Speedy fixation, locking, replacement, and positioning of parts and processed products.
Ideal for areas that are frequently attached and detached.
The material of the pin is equivalent to SUS303.
It has corrosion resistance.
It has a compact shape with a recessed part that is easy to put your finger on.
A holding cable (EH22400.0970/0974 sold separately) can be installed. Please contact us for other mounting methods.
【Use】
For locking adjustment mechanisms, fastening detachable parts, fixing movable parts, and as a substitute for screws and fasteners.
【Specification】
Shear strength (kN): 21
d1: 6
d2: 7.0
d3: 10
l1: 30
l2: 7.0
l3: 26.2
Mounting hole H11: 6
【Specification2】
Self-locking function
With unlocking function
Straight type
Hole tolerance is H11
Maximum operating temperature: 250℃
【Material/Finish】
Pin part: Stainless steel 1.4305 (equivalent to SUS303)
Spring: Stainless steel
【Set contents/accessories】
-
【caution】
-
