Ball Lock Pins, Self-Locking, with Adjustable Clamping Span 22370.0659 HALDER Quality From China Wholesale

【Features】
Quickly fixes parts and processed products.
Length can be adjusted with a nut.
The length of the clamp can be adjusted steplessly by turning the nut and counter nut by hand.
It has corrosion resistance.
A holding cable (EH22400.Sold separately) can be installed.

【Use】
For locking adjustment mechanisms, fastening detachable parts, fixing movable parts, and as a substitute for screws and fasteners.

【Specification】
Shear strength (kN): 155
d1: 16
d2: 19.0
d3: 29.0
l1: 350 ~ 45
l2: 14.0
l3: 36.7
l4: 39.5
l5: 21.8
Mounting hole H11: 16
d4 :34.6

【Specification2】
Self-locking function
With lock release function
Mounting hole tolerance: H11
Operating temperature range: -30~80℃
With length adjustment mechanism

【Material/Finish】
Pin part: Stainless steel 1.4305 (equivalent to SUS303)
Spring: Stainless steel
Adjusting nut: Thermoplastic resin, silver
Lock nut: Thermoplastic resin, black
