Ball Valve with Safety Lock BAV-LSF20A TRUSCO Cheap Buy Authentic

【Features】
Equipped with an opening/closing lock mechanism to prevent malfunction.
Can be unlocked with one finger.
Full-bore type with low pressure loss, suitable for piping with large flow rate.

【Use】
For water, oil, and air.

【Specification】
Nominal diameter A: 20
Nominal diameter B: 3/4
Overall length (mm): 65
Height (mm): 47
Handle length D (mm): 116
Maximum allowable pressure (MPa): 2.8MPa (at room temperature water/oil), 1.0MPa (air at room temperature), 0.7MPa (water/oil/air below 120℃)

【Specification2】
Maximum allowable pressure: 2.8MPa (room temperature water/oil), 1.0MPa (room temperature air), 0.7MPa (cold water/oil/air below 120 degrees)
Full bore type

【Material/Finish】
Body: Bronze (CAC406)
Ball: SUS304

【Set contents/accessories】
－

【caution】
－
