Clamp Meter DCM600DR SANWA Cheap 100% Authentic

【Features】
Can measure AC/DCA up to 600.0A.
True effective value measurement is possible.
Equipped with backlight.
Equipped with peak hold function (1 ms)
True RMS value detection method allows measurement of distorted waveforms
Relative function (relative value display), data hold function
Equipped with a removable auto power save function that activates after about 30 minutes

【Use】
For maintenance of equipment.
For maintenance of power equipment such as automobiles.

【Specification】
DC current (A): 600
Alternating current (A): 600
DC voltage (V): 600
AC voltage (V): 600
Resistance (Ω): 999.9
Detection method: True RMS method (RMS) )
Calibration documents: Available
Power supply (V): AAA alkaline batteries (LR03) x 2 (included)
Width (mm): 69
Depth (mm): 38
Height (mm): 208
Power supply : AAA alkaline battery (LR03) x 2 (included)
Continuity check: Buzzer sounds when approx. 40Ω or less Open voltage 2.9V
Maximum measurement conductor diameter: 50mm
Clamp diameter: 30mm

【Specification2】
Maximum display: 6000 counts
Width x depth x height: 69 x 38 x 208mm
Battery life: 40 hours

【Material/Finish】
－

【Set contents/accessories】
Test lead
Carrying case
Instruction manual
Mobile case C-DCM660
Test lead TL-23a

【caution】
This instrument is a clamp meter for low voltage. Do not use on electrical circuits where the voltage to ground exceeds 600V.
Do not switch to other functions during measurement.
Be sure to wear insulating protective equipment such as electrical rubber gloves when attaching or detaching to live conductors.
Do not input signals exceeding the maximum rated input value.
During measurement, do not hold the test probe on the test pin side or beyond the clamp sensor barrier.
