CLAMPS B-TYPE B150A LOBSTER High Quality

【Features】
The swing angle of the plate part is 15° and can be replaced.
The shaft head is hexagonal and can be tightened with a wrench.
If the plate comes off, it can be installed without special tools.
Precise forging provides sufficient forging strength for long-term use.
Thorough heat treatment fully demonstrates the toughness characteristic of special steel.
High-precision square screws have little backlash and open and close smoothly.

【Use】
Fixing and holding workpieces during welding and drilling work.

【Specification】
Maximum opening (mm): 151
Jaw depth (mm): 75
Male thread hexagonal width across flats (mm): 23
Dish angle (°): 15
Length (mm): 273
Type: Barco type
Guaranteed strength (kN): 32.7
Body height (mm): 150
Counter diameter (mm): φ30
Thread thickness (mm): 19.3
Hexagonal part width across flats (mm): 23
Counter collar width across flats (mm): 24

【Specification2】-Plates can be replaced

【Material/Finish】
Special steel (body: forged product)

【Set contents/accessories】
－

【caution】
Do not use as a hanging device.
Do not connect it to scaffolding or attach it to anything to use it as a scaffold.
Tighten securely.
Do not apply shock by hitting it with a hammer, etc.
Do not use by adding pipes, etc.
