DHO5108 Rigol Digital Oscilloscope Cheap Sale Visit

Features:

• 8 channels / 1 GHz (800 MHz on all channels)
• Maximum sample rate: up to 4 GSa/s (single, half channel); 2 GSa/s (full channel)
• Half channel mode is when Ch 1,3,5,7 or Ch 2,4,6,8 are enabled
• 12-bit resolution (up to 16-bit in high resolution mode)
• Standard: parallel, RS232/UART, I2C, and SPI
• Standard interfaces: USB Device, USB Host, LAN, HDMI
• 10.1” touch screen (1280 x 800)
• 256-level intensity grading display, with digital real-time fluorescence technology
• This model does not have mixed signal analysis functionality (see MHO5000 for MSO usage)

Digital Oscilloscope (8 Channels / 1 GHz)

The Rigol DHO5000 series is a high-resolution digital oscilloscope designed to satisfy a variety of design, debugging, and testing requirements. Based on RIGOL’s brand new self-developed Centaurus platform, it features 12-bit resolution, with excellent noise floor and vertical measurement accuracy.

DHO5000 overview

DHO5000 models do not have logic analysis or waveform generation functionality.

Software options

Rigol offers a variety of software options for users to customize the oscilloscope to their specific application. Part numbers and descriptions can be seen below. Please note – parallel, RS232/UART, I2C, and SPI are included standard.

• DHO5000-AEROA – MIL-STD-1553
• DHO5000-AUDIOA – I2S
• DHO5000-AUTOA – CAN/CAN-FD, LIN
• DHO5000-BND – Software option bundle
• DHO5000-FlexA – FlexRay
• DHO5000-PWRA – Power Analysis
• DHO5000-SENTA – SENT
