Type K Thermocouple Probe 1/16″ Diameter 12 Inch Long Stainless Steel Sheath Ungrounded with FEP Lead Wire. Stripped Ends or Connector Termination Sale Release Dates

Type K Thermocouple Probe 1/16″ Diameter 12 Inch Long Stainless Steel Sheath Ungrounded with FEP Lead Wire. Stripped Ends or Connector Termination

• Temperature Operating range of the probe sheath is 32 to 1,690°F (0 to 920°C)
• Probe is a 12 inch long 1/16″ (.0625″ or 1.59 mm) diameter 316 Grade Stainless Steel MI Cable sheathing
• MI Cable sheath is Bendable to maxium of 2.5 to 3 times the diameter of probe sheath.
• Transition is 3/8″ diameter stainless steel backfilled with 400°F (200°C) high performance epoxy and a stainless steel spring providing strain relief to the lead wire.
• Wire Leads are 3.3ft (40 Inches or 1 meter) long.
• Custom Lengths available
• Wire Construction is 24 gage stranded (7/32 – 7 strands of 32 gage (.008″) diameter) thermocouple wire in a 2 wire parallel construction and insulated with 400°F (200°C) rated FEP. Overall dimension is .060″ x .100″
• Color Code is ANSI with a yellow insulated nickel chrome positive wire, red insulated nickel aluminum negative wire and brown overall jacket.
• Instrument Connection – stripped wire lead or miniature flat pin male connector
• The plastic body of the connector has a rating of -40 to 400°F (-40 to 200°C) and accurately transfer the full range of Type K thermocouple
• Evosensors Part Numbers:
• K1X-S304-062-UX-12-PFXX-40-STWL (stripped wire ends design)
• K1X-S304-062-UX-12-PFXX-40-MPCX (miniature male flat pin connector)
• Location: C-6-14
